1.8mm Gap 700cd Floor Stand 4x3 Video Wall With Split Screen Advertising Display
LCD splicing screen product features
High-definition industrial panel, ultra-narrow-edge LCD seamless splicing, can realize multi-screen display format, free combination splicing.
3D digital comb filtering and 3D digital image noise reduction, clear image and wide field of view;
With automatic adjustment function of VGA status image reappearance rate;
Uniform brightness, stable image, no flicker, no distortion, large screen without curvature, it is a model of flat panel display device;
Extremely long life and extremely low maintenance costs: the whole machine has a life of 80,000 hours and the image is stable without any changes after long hours of work;
Through splicing, it is possible to make large-size (such as 200-inch, 300-inch, etc.) LCD LCD display screens;
Liquid crystal (LCD) large screen splicing wall has a beautiful wall, compact overall structure, which can save a lot of space for use, good heat dissipation, and can adapt to long-term work in various environments
LCD splicing screen installation method
Common installation methods can be divided into four categories: wall mount, floor stand, cabinet, and recessed installation.
The main considerations for wall-mounted and recessed installations are the bearing capacity of the wall and the thickness of the wall.
Cabinets and floor stands are used when the wall's load-bearing capacity does not meet actual needs.
In general, a set of LCD splicing screen wall with more than 10 LCD splicing units is usually recommended to use a floor stand or cabinet for installation.
LCD splicing screen application
Government, enterprise, school, airport flight, subway and other communication information release;
Advertising and multimedia system display in hotels, shopping malls, real estate, theater concerts, convention centers, stadiums and other places;
City management emergency command center, traffic management command center, monitoring system, government enterprise multimedia video conference display system.
LCD splicing screen service
Screen body warranty period: 1 year; accessories warranty period is 2 years, lifetime maintenance.
Free warranty (including labor and materials): free warranty during the warranty period, after the warranty period, guarantee a reasonable price to provide spare parts and maintenance services.
Response time: Received user notification to ensure 24 hours uninterrupted after-sales technical service support.
Spare parts / spare parts: The necessary spare parts / spare parts have been prepared for the user unit before the display leaves the factory.
Telephone return visit: During the warranty period, the company's after-sales service department will contact the user by phone every month to understand the product usage, and to find problems and solve problems at any time.
Software upgrades: Maintain the system continuously throughout life, and continuously improve system functions and software upgrades.
Provide local installation guidance services.
LCD splicing panel specification:
| 55" splicing screen details |
| Gap | 1.8mm | Panel brand | LG |
| pane type | a-si TFT-LCD | display mode | 16:9 |
| display area | 1209.6mm(W)*684.4mm(H) | Max resolution | 1920*1080 |
| Dot pitch (mm) | 0.63(H)*0.63(V) | display color | 16.7M |
| Contrast | 4000:1 | Brightness | 700cd/㎡ |
| Max power loss | ≤400W | view angle(up/down/left/right) | 178°/178°/178°/178° |
| Dimension(L×H×W) | 1213.4mm*684.2mm*54.7mm | response time | 8ms |
| Field frequency | 50HZ,60HZ,70HZ, | Compatible HD TV inputs | 480P,576P,720P,1080I,1080P |
| Composite video input | 5 road BNC(BNC*5) input | 3D Comb filtering | with |
| Composite video output | 2 road BNC(BNC*2)output, Can be connected to video equipment | Video noise reduction | with |
| Serial control | 1 road RS232-RJ45(568B)input | Menu lanuage(option) | Chinese/English |
| Serial control | 1road RS232-RJ45(568B)output | Power | AC100V~240V,50/60Hz |
| VGA input | 1 road D-SUB VGA input | Standby power loss | ＜1W |
| HDMI/HDMI | 1 road HDMI input | Cooling system | Ultra-quiet dual fan cooling with temperature control |
| DVI/DVI | 1 road DVI input | Case material | Rugged metal case |
| Color system | PAL/NTSC/ Automatic Identification | Accessories | Wall mount bracket, power cord, remote control 232 to RJ45 serial port connector, mounting screw (M6 * 20), software manual, warranty card, certificate |
